From the 2024 UPC Illustrated Training Manual, Chapter 9 – VENTS
911.3 Relief Vent. A 2 inch (50 mm) relief vent shall be provided for circuit-vented horizontal branches receiving the discharge of four or more water closets when connecting to a drainage stack that receives the discharge of soil or waste from upper horizontal branches.
There are two conditions that mandate the installation of a relief vent for a circuit-vented horizontal branch:
1) when the circuit-vented horizontal branch receives the discharge of four or more water closets, and
2) when the circuit-vented horizontal branch connects to a stack that receives discharges from upper floor fixtures.
See Figure 911.3.
RELIEF VENT
From the 2024 UMC Illustrated Training Manual, Chapter 12 – HYDRONICS
1217.1.1 Manifolds. Manifolds shall be equipped with isolation valves on the supply and return lines. Manifolds shall be capable of withstanding the pressure and temperature of the system. The material of the manifold shall be compatible with the system fluid and shall be installed in accordance with the manufacturer’s installation instructions.
Manifolds are mainly used to control separate zones and are required for systems that require more than one water temperature. It is crucial to maintain manifolds in proper working conditions, thus requiring isolation valves for servicing and maintenance. See Section 1212.0 for isolation valve requirements.
(This is not to be considered the official position of IAPMO, nor is it an official interpretation of the Codes.)
